C1448
Parts associated with C1448
- 02-2628-02 — Receiver
- 02-3319-02 — Dryer
- 02-3575-01 — Fan guard A37296-001 Leg brace - ERC611
- 02-3692-21 — Drain adapter - also for WC and RC
- 02-4064-01 — Water distributor, left 8R 11-0563-03 Curtain switch, right
- 02-4064-02 — Water distributor, right
- 02-4065-01 — Water distributor cover 8L 11-0563-06 Curtain switch, left
- 02-4067-03 — Side panel support. Fits
- 02-4067-04 — Front side panel support for
- 02-4076-01 — Control box door 12-2944-02 Hi voltage
- 02-4152-01 — Gusset
- 02-4156-21 — Spillway replacement kit
- 02-4175-01 — Rt side res cover
- 02-4177-01 — Water pump bracket
- 02-4178-01 — Reservoir cover (prior)
- 02-4182-01 — Pump hose
- 02-4184-01 — Evaporator cover
- 02-4189-01 — Overlay label Hi voltage harness has the
- 02-4205-01 — Mounting bracket, left
- 02-4205-02 — Mounting bracket, right
- 02-4212-01 — Air filter
- 02-4212-03 — Filters
- 02-4214-03 — Trim strip
- 02-4215-01 — Receptacle
- 02-4216-01 — Top gusset
- 02-4217-01 — Bottom gusset
- 02-4221-01 — Left trim strip
- 02-4221-02 — Right trim strip
- 02-4224-01 — Louver panel
- 02-4224-03 — Louvers
- 02-4284-01 — Bezel, full window
- 02-4284-02 — Bezel, partial window
- 02-4332-01 — Sensor cover (prior)
- 02-4611-21 — Curtain
- 02-4646-01 — WLS guard, use/w
- 02-4649-01 — Sump cover, use/w
- 02-4819-03 — Trim strip
- 02-4820-03 — Trim strip bottom
- 02-4821-02 — Bezel with standard door
- 02-4822-02 — Bezel with secure door
- 02-4823-21 — *Panel mount kit, left
- 02-4823-22 — *Panel mount kit, right
- 02-4824-01 — Spacer A40310-022 Left side panel WC, RC
- 03-0727-05 — Screw
- 03-1404-10 — Screw
- 03-1404-12 — Screw
- 03-1405-08 — Screw A37170-001 Leg brace - ECR311
- 03-1405-15 — Screw
- 03-1419-17 — Flat head screw
- 03-1419-26 — Screw
- 03-1645-01 — Screw
- 03-1733-04 — Ball stud Receptacle
- 03-1735-03 — Screw, front panel
- 03-3804-01 — Screw receptacle
- 03-3836-02 — Screw
- 03-3868-01 — Screw
- 11-0422-22 — Headmaster 03-1645-01 Screw for legs
- 11-0478-02 — Water regulating valve C2148W
- 11-0493-01 — Hot gas valve
- 11-0501-21 — High pressure sw.
- 11-0501-22 — High pressure cut out
- 11-0563-02 — Curtain switch magnet*
- 11-0563-03 — Curtain switch, right
- 11-0563-06 — Curtain switch, left
- 11-0564-02 — Purge valve
- 11-0566-22 — Fan cycle pressure sw.
- 11-0568-02 — Inlet water sol vlv, CE mod
- 11-0572-21 — Temp probe assy
- 11-0608-21 — Water regulating valve, C1448W
- 11-0621-21 — Service controller, fits all 12-2938-01 Hi voltage harness, Rem
- 11-0622-21 — Light & switch panel D
- 12-1213-11 — Snap bushing Power harness connects to J1 on controller
- 12-1213-15 — Snap bushing
- 12-2469-02 — Contactor, 230, single ph
- 12-2533-02 — Contactor, three phase Wiring Harnesses (not illustrated)
- 12-2639-01 — Transformer
- 12-2651-01 — Fan motor - ERC311 16-1100-08 on Quick connect w/ stub for 3/8
- 12-2686-01 — Fuse
- 12-2687-01 — Fuse holder
- 12-2717-01 — Fan motor - ERC611
- 12-2733-30 — HGV rebuild kit
- 12-2912-01 — Water valve rebuild kit
- 12-2920-22 — Water pump
- 12-2920-26 — Water pump
- 12-2922-02 — Inlet water sol vlv
- 12-2924-02 — Transformer
- 12-2928-01 — Water level sensor harness
- 12-2928-02 — Water level sensor harness
- 12-2931-01 — Power harness, A & W
- 12-2931-02 — Power harness, Remote
- 12-2937-01 — Hi voltage harness, A & W
- 12-2938-01 — Hi voltage harness, Rem
- 12-2944-01 — Hi voltage
- 12-2944-02 — Hi voltage
- 12-3010-03 — Contactor
- 12-3060-22 — Harvest assist solenoid
- 12-3066-02 — Hi voltage
- 13-0674-02 — Fill hose order by ft (18')
- 13-0943-01 — Gasket tape
- 15-0411-00 — Strike - A series only 12-2920-26 Water pump
- 15-0821-01 — Fill hose, -6 CE models
- 16-0355-00 — Inlet water fitting, flare
- 16-0832-02 — Stem cap
- 16-0832-03 — Port cap
- 16-0832-20 — Access valve
- 16-0850-01 — Discharge quick connect
- 16-0850-03 — Liquid quick connect
- 16-1030-01 — Liquid line access valve
- 16-1063-01 — Strainer
- 16-1100-08 — on Quick connect w/ stub for 3/8
- 16-1100-09 — Quick connect w/ stub for 1/2
- 16-1122-21 — Accumulator, kit w/insul
- 16-1130-01 — TXV 10b 16-1140-01 Cap
- 16-1137-01 — Valve body
- 16-1139-01 — Core
- 16-1140-01 — Cap
- 16-1177-01 — Receiver
- 16-1208-01 — 3/8 Isolation valve - E series
- 16-1208-02 — 1/2 Isolation valve - E series
- 18-8816-01 — Fan blade - ERC311 16-0850-01 Quick connect, discharge
- 18-8819-01 — Coil, ERC611
- 18-8820-01 — Fan blade - ERC611 16-0850-03 A-D Quick connect, liquid
- 18-8827-01 — Coil, ERC311
- 18-8840-02 — Bracket
- 18-8865-01 — Condenser, WC C1448. C1848
- 18-8882-01 — Fan blade
- 18-8892-01 — Condenser, AC 10a 16-1139-01 Core
- 18-8927-01 — Fan motor All but C1848 E
- 18-8927-02 — C1848 E Fan motor
- 18-8931-21 — Condenser, WC C2148
- 19-0599-06 — Insulation Danfoss TXV
