C1800CP
Parts associated with C1800CP
- 02-3231-02 — Filter C1200CP-2 three phase 18-8750-24
- 02-3231-03 — Filter
- 02-3319-02 — Filter drier Single phase compressors include starting
- 02-3575-01 — Fan guard
- 02-3692-21 — Drain fitting
- 02-3770-01 — Fan guard
- 02-4045-01 — Insulation for TXV
- 02-4064-01 — Water distributor, left
- 02-4064-02 — Water distributor, right
- 02-4065-01 — Water distributor cover
- 02-4067-01 — Side panel support
- 02-4067-03 — Side panel support
- 02-4100-32 — Curtain
- 02-4175-01 — Sump cover, rt
- 02-4177-01 — Pump bracket
- 02-4178-01 — Sump cover, prior, fits
- 02-4182-01 — Water pump hose, EH430
- 02-4184-01 — Evaporator cover
- 02-4205-01 — Mounting bracket, left Note
- 02-4205-02 — Mounting bracket, right
- 02-4214-02 — Trim strip
- 02-4215-01 — Receptacle
- 02-4216-01 — Top gusset
- 02-4217-01 — Bottom gusset
- 02-4221-01 — Left trim strip
- 02-4221-02 — Right trim strip
- 02-4284-01 — Bezel, full window
- 02-4284-02 — Bezel, partial window
- 02-4332-01 — WLS cover, prior fits
- 02-4504-01 — Evaporator cover
- 02-4505-01 — Water pump hose, EH330
- 02-4611-21 — Curtain
- 02-4646-01 — Probe guard, fits 21a
- 02-4649-01 — Sump cover, fits 8a
- 03-0727-05 — Screw
- 03-1404-12 — Screw
- 03-1404-15 — Cap screw
- 03-1405-08 — Screw
- 03-1405-15 — Screw
- 03-1406-07 — Washer
- 03-1531-01 — Screw
- 03-1645-01 — Screw
- 03-1735-03 — Screw, front panel
- 03-3804-01 — Screw receptacle * Side trim strips discontinued
- 03-3868-01 — Screw
- 11-0422-22 — Headmaster C1200CP-32 single phase 18-8750-22
- 11-0493-03 — Vapor valve
- 11-0501-22 — Hi pressure cut out
- 11-0507-03 — By pass valve
- 11-0546-01 — Liquid inlet valve
- 11-0550-28 — Controller
- 11-0563-02 — Curtain switch magnet
- 11-0563-03 — Curtain switch, right
- 11-0563-06 — Curtain switch, left
- 11-0564-01 — Purge valve
- 11-0572-21 — Temp sensor set
- 12-1213-11 — Snap bushing
- 12-1213-15 — Snap bushing
- 12-1213-20 — Snap bushing
- 12-1638-19 — Power cord
- 12-2469-01 — Single phase contactor
- 12-2533-01 — Three phase Contactor
- 12-2637-01 — Toggle switch
- 12-2651-01 — Fan motor
- 12-2717-01 — Fan motor
- 12-2780-01 — Terminal strip
- 12-2836-02 — Transformer
- 12-2920-21 — Water pump
- 12-2922-01 — Inlet water sol valve
- 12-2924-01 — Transformer
- 12-2928-01 — WLS harness, wire to
- 12-2940-01 — Control power harness
- 12-2943-01 — High voltage harness (has
- 12-2949-01 — Relay
- 12-2949-02 — Relay base
- 12-2954-01 — Low voltage harness - to
- 12-3060-21 — Harvest assist
- 13-0674-02 — Tubing, order
- 13-0943-01 — Gasket tape
- 16-0355-00 — Inlet water fitting, flare
- 16-0701-07 — Mounting flange 03-1404-15 Cap screw
- 16-0701-14 — Mounting flange
- 16-0701-18 — Mounting flange
- 16-0801-22 — Accumulator
- 16-0832-20 — Access valve
- 16-0850-01 — Vapor line fitting
- 16-0850-03 — Liquid line fitting
- 16-0850-04 — Suction line fitting
- 16-1029-01 — Check valve
- 16-1057-03 — Quick connect, liquid
- 16-1057-04 — Quick connect, disch
- 16-1063-01 — Strainer
- 16-1085-01 — Receiver All compressors are 208-230 volt
- 16-1096-21 — CPR valve
- 16-1122-21 — Accumulator
- 16-1130-01 — TXV - EH430
- 16-1142-01 — TXV - EH330
- 18-2300-26 — Sleeve
- 18-2300-27 — Mounting grommet
- 18-8816-01 — Fan blade
- 18-8820-01 — Fan blade
