CME506R

Find Parts for CME506R

Browse OEM replacement parts for the CME506R ice machine and use the parts diagram below to identify the correct component before ordering.

View Parts Diagram for CME506R

Looking to buy a new ice machine

to replace this model? Request a Quote →

Parts associated with CME506R

02-0540-00 — Scoop
02-1875-03 — Panel bumper/hole plug
02-2380-02 — Spacer
02-2527-01 — Water distributor
02-2806-01 — Shoulder screw
02-2809-02 — Drain top
02-2920-01 — Insulation for TXV
02-3108-01 — Drain bottom
02-3196-01 — Hinge
02-3231-02 — Liquid line
02-3231-03 — Discharge line
02-3274-02 — Door frame - Grey
02-3319-02 — Dryer
02-3336-01 — Water distributor tube
02-3337-01 — Cube deflector
02-3338-01 — Drain tube & fittings
02-3339-01 — Stand pipe
02-3340-01 — Reservoir cover
02-3341-01 — Float
02-3360-01 — Reservoir washer
02-3383-02 — Float stem grey, non adjustable after 2/97
02-3388-04 — Front pump bracket for 12-2586 type pump
02-3388-05 — Rear pump bracket for 12-2586 type pump
02-3396-01 — Insulation for TXV
02-3405-01 — Inlet Tee
02-3410-21 — Discharge line temperature sensor, includes
02-3575-01 — Fan guard
02-3610-01 — Stand pipe adjusting nut
02-3657-01 — Cascading shield, use began
02-3659-01 — Top insulation
02-3663-01 — Evaporator cover, use began Feb. 1997. For A and B series
02-3663-20 — Evaporator cover w/ins for C - higher series
02-3792-01 — Insulation for TXV
02-3794-31 — Trim strip.
02-3796-01 — Evap cover insulation for above cover
02-3797-21 — C series Front panel kit, gray plastic, includes trim strip & emblems
02-3822-21 — Top panel, plastic, original with D series, fits all and includes
03-0271-00 — is the speed nut for emblem
03-0727-11 — Thumb screw
03-1403-19 — Machine screw for D series
03-1404-07 — Screw
03-1404-12 — Sheet metal screw for plastic front panel (for A series)
03-1404-18 — Screw
03-1406-13 — Nut
03-1410-06 — Washer
03-1419-22 — Sheet metal screw for ss front panel
03-1423-06 — Speed nut for panel screws
03-1531-01 — Sheet metal screw for A - C series
03-1539-09 — E-Ring
03-1638-03 — Screw
03-1645-01 — Screw
03-1691-01 — Nylon screw
03-1711-01 — Sensor clip
03-1731-02 — Push nut for trim strip
03-1733-01 — Strike (for C model panel, SS and plastic)
03-1733-02 — Catch
03-1735-01 — Screw for trim strip (for C or D or E series)
05-0586-01 — Drain elbow
11-0422-23 — Discharge pressure control valve
11-0422-24 — Discharge pressure control valve
11-0501-22 — Hi pressure cut out switch
11-0502-21 — Pump down pressure switch
11-0539-51 — Float sensor
11-0540-21 — Bin Control Sensor (set)
12-1868-01 — Crankcase heater
12-2308-01 — Crankcase heater
12-2471-22 — Hot gas valve complete
12-2471-23 — Liquid line valve
12-2471-24 — Hot gas valve complete
12-2506-01 — Harness
12-2541-21 — Hi Voltage harness A - C
12-2548-01 — Inlet water valve
12-2586-23 — CME656 or CME506-6 or CME806 (203-230/50-60 Hz) pump
12-2586-27 — CME506-1 pump (115/60 Hz)
12-2644-02 — Lo voltage harness A - C
12-2719-23 — Hot gas valve coil
12-2782-02 — Lo voltage harness, D + series
12-2785-01 — Hi voltage harness - D series
12-2838-24 — System controller, fits all
13-0617-09 — O-Ring
13-0617-56 — O-ring
13-0674-02 — Tubing, 9' req., order
13-0840-01 — Rubber plug
13-0898-01 — Tubing grommet
13-0903-01 — Bumper for side panels
13-0906-01 — Plastic Inlet water tube, 21'
13-0909-01 — Door gasket, order
15-0792-02 — Emblem for C to E series front panel, (CM3)
15-0808-01 — Emblem for ss panel (Scotsman); 03-0271-00 is the speed nut for emblem
16-0701-07 — Mounting flange
16-0761-01 — Receiver
16-0776-01 — Tee
16-0778-21 — Accumulator
16-0832-02 — Stem cap
16-0832-03 — Port cap
16-0832-20 — Access valve
16-0843-02 — Distributor and tubes
16-0843-03 — Distributor and tubes
16-0850-01 — Discharge line fitting
16-0850-03 — Liquid line fitting
16-0997-01 — Inlet water fitting for hose
16-1009-22 — TXV - only for E series
16-1017-21 — TXV
16-1019-01 — Inlet water fitting for copper
16-1020-01 — Water fitting for copper
16-1063-01 — Hot gas valve strainer, not shown
16-1071-01 — Check valve
16-1076-21 — TXV (interchangeable with all
16-1095-01 — Restrictor
17-2748-01 — USE COPPER CONDUCTORS ONLY
17-2751-01 — USE COPPER CONDUCTORS ONLY
17-2758-01 — USE COPPER CONDUCTORS ONLY
18-1901-03 — 18-1901-43 18-1901-15 not used 18-1901-52 18-1901-48 18-1901-48
18-1901-15 — not used 18-1901-52 18-1901-48 18-1901-48
18-1901-43 — 18-1901-15 not used 18-1901-52 18-1901-48 18-1901-48
18-1902-30 — 18-1902-53 not used 18-1902-53 18-1902-55 18-1902-55
18-1902-45 — 18-1902-30 18-1902-53 not used 18-1902-53 18-1902-55 18-1902-55
18-1902-53 — not used 18-1902-53 18-1902-55 18-1902-55
18-1903-29 — 18-1903-33 not used 18-1903-29 18-1903-46 18-1903-33
18-1903-33 — not used 18-1903-29 18-1903-46 18-1903-33
18-1903-50 — 18-1903-29 18-1903-33 not used 18-1903-29 18-1903-46 18-1903-33
18-8711-50 — 18-8721-50 internal internal internal internal internal
18-8721-50 — internal internal internal internal internal
18-8796-01 — Fan motor ERC101
18-8796-32 — Fan motor ERC201, ERC402
18-8800-01 — Fan blade
19-0503-04 — Gasket, order
