Ice-O-Matic ICE2005 Parts Breakdown | Genuine OEM Parts

9131332-02 BLADE FAN 38 DEG 10 IN, ICEOMATIC

9131026-02 CAPLUG 1-3/8 W/ HOLE, ICEOMATIC

9091080-01 FITTING BARREL, ICEOMATIC

2041338-01 TUBE WATER DIST LH ASSY, ICEOMATIC

2041338-02 TUBE WATER DIST RH ASSY, ICEOMATIC

9181010-04 RELAY POTENTIAL, ICEOMATIC

9181010-10 RELAY POTENTIAL, ICEOMATIC

9181010-11 RELAY POTENTIAL, ICEOMATIC

9181009-20 CAPACITOR RUN 40MFD 370V, ICEOMATIC

9181009-13 CAPACITOR RUN 40MFD 440V, ICEOMATIC

9181003-34 CAPACITOR ST 219-259@330, ICEOMATIC

9181003-21 CAPACITOR ST 189-227@330, ICEOMATIC

9161079-02 YPUMP WATER 3000 RPM, ICEOMATIC

9151123-04 COIL SOL VALVE 230V, ICEOMATIC

9151123-01 BODY SOL VALVE 200RB 3T3, ICEOMATIC

9151123-02 BODY SOL VALVE 200RB 4T3, ICEOMATIC

9151027-06 VALVE HEAD PRESS 240LB, ICEOMATIC

9151134-02 YVALVE THERMO EXP, ICEOMATIC

9151109-01 RECEIVER ICE1800-2100R, ICEOMATIC

9141061-02 CONDENSER WATER, ICEOMATIC

9141123-01 CONDENSER WATER, ICEOMATIC

9131111-02 FLOAT VALVE PLASTIC, ICEOMATIC

9101084-02 RELAY 2 POLE 240 V, ICEOMATIC

9101195-01 SWITCH ROCKER DPDT, ICEOMATIC

9101139-03 SWITCH ROCKER SPDT, ICEOMATIC

9101148-01 TIMER MODULE, ICEOMATIC

9101083-01 SOCKET RELAY 2 POLE, ICEOMATIC

9101160-01 SWITCH LIMIT SPDT, ICEOMATIC

9101079-02 CONTACTOR 3P 230V 30A, ICEOMATIC

9101002-04 YCONTACTOR 230 V 30 AMP, ICEOMATIC

9091001-12 COUPLING HALF 1/2 W/ STU, ICEOMATIC

9091083-01 FITTING WATER INLET, ICEOMATIC

9091074-01 FITTING DROP ADAPT 3/8FP, ICEOMATIC

9091001-11 COUPLING HALF 3/8 W/ STU, ICEOMATIC

9091063-02 FITTING DROP ADAPT 1/2FP, ICEOMATIC

9091081-01 FERRULE, ICEOMATIC

9091001-08 COUPLING HALF TUBING 1/2, ICEOMATIC

9091001-10 COUPLING HALF W/VLV 1/2, ICEOMATIC

9091001-04 COUPLING HALF W/ VLV 3/8, ICEOMATIC

9091001-02 COUPLING HALF TUBING 3/8, ICEOMATIC
