QM45A
Click Here for QM45A Parts Breakdown
Parts associated with QM45A
- 7629073 — Control Board
- 2511493 — 10 Amp Fuse
- 2301513 — Toggle Switch
- 2032483 — Wiring Harness - Toggle Switch
- 8505533 — Relay - 115V/60 Hz/1 Ph
- 8505543 — Relay - 230V/50-60 Hz/1 Ph
- 2008303 — Wiring Harness - Air-cooled
- 040001218 — Power Cord - 115V/60 Hz
- 2033023 — Power Cord - 230V/50-60 Hz
- 4302253 — Control Board Mounting Supports
- 5202323 — Screw, #10-24 x .50 Ground
- 2500139 — Bushing - 1.5"
- 2502189 — Bushing - 0.625"
- 7629463 — Evaporator - Dice Cube
- 7623063 — Water Pump - 115V/60 Hz
- 7626013 — Water Pump - 230V/50-60 Hz
- 040000946 — Water Pump - 230V/50-60 Hz
- 040001514 — Water Pump Mounting Plate
- 7602133 — Float Valve Assembly
- 8369049 — Float Valve Assembly
- 8369069 — Float Valve Screen
- 8369089 — Float Valve Plunger
- 5650729 — Float Valve Compression Nut
- 7621403 — Float Valve Bracket
- 7601603 — Ice Thickness Control Probe
- 2301483 — Magnetic Bin Switch
- 7600493 — Ice Damper
- 7629093 — Ice Damper Magnet and Cap
- 000007163 — Water Distribution Tube - QM30/QM45
- 040001233 — Water Trough
- 4420291 — Vinyl Tube - 0.25" OD
- 4302223 — Siphon Cap
- 000006754 — Water Pump Cover
- 7600863 — Drain Tube
- 040001234 — Water Pump Tubing
- 5202189 — Evaporator Mounting - Screw - #10-24 x 0.75"
- 5202069 — Screw - #10-24 x 0.50" HEX
- 040001217 — Thumbscrew - #8-32 x 0.625"
- 2500169 — Bushing - 0.91" OD x 0.44" ID
- 2078063 — Water Pump Lead - 208-230V/50-60 Hz
- 7629183 — Compressor - 115V/60 Hz/1 Ph
- 8505683 — Overload / Relay Assembly
- 7629193 — Compressor - 230V/50 Hz/1 Ph
- 8505503 — Overload / Relay Assembly
- 7630001 — Solenoid Valve with Electrical Coil - 115V/60 Hz
- 000005156 — Danfoss Solenoid Valve Coil Only - 115V/60 Hz
- 2404363 — Alco Solenoid Valve Coil Only - 115V/60 Hz
- 7630061 — Solenoid Valve with Coil - 208-230V/50-60 Hz
- 000005157 — Danfoss Solenoid Valve Coil Only - 230V/50-60 Hz
- 2404483 — Alco Solenoid Valve Coil Only - 230V/50 Hz
- 7629503 — Expansion Valve
- 4007213 — Valve Insulation Boot - Body
- 4007203 — Valve Insulation Boot - Bulb
- 6035151 — Coupling Panel - Water/Electrical Connections
- 8706093 — Female Wing Adapter - 0.375"
- 1360961 — Male Connector
- 4421443 — Bin Drain Tubing - 0.625 ID
- 5650649 — Hose Clamp - 0.759"/0.848" ID
- 5650529 — Clamp - Expansion Valve Bulb
- 5648269 — Mounting - Retainer
- 5573179 — Compressor Mounting Washer
- 3712109 — Clevis Pin - 0.25" x 1"
- 5648289 — Hairpin Clip
- 8851353 — Air Condenser
- 2000223 — Fan Motor - 115V/60 Hz/1 Ph
- 2000219 — Fan Motor - 208-230V/50-60 Hz
- 2416243 — Fan Blade
- 2355453 — Fan Cycling Control
- 8930259 — Drier
- 6061749 — Fan Shroud
- 6029401 — Fan Motor Mounting Bracket
- 7629213 — Front Panel Assembly
- 7629223 — Air Filter
- 040000627 — Door Frame Assembly
- 040002220 — Bin Door
- 7629233 — Door Pin Gasket and Door Pin Assembly
- 5012353 — Door Pin Thumbscrews
- 6047101 — Back Panel, Upper
- 6029461 — Back Panel, Lower
- 5202239 — Front Cover Screw
- 5121539 — Panel/Condenser Mounting Screw - #8 x 0.50"
- 3302583 — Ice Scoop
