RF2300W
Find Parts for RF2300W
Browse OEM replacement parts for the RF2300W ice machine and use the parts diagram below to identify the correct component before ordering.
View Parts Diagram for
RF2300W
Buy Filters for this Model
Looking to buy a new ice machine
to replace this model?
Request a Quote →
Parts associated with RF2300W
- 000005682 — Evaporator Assembly
- 000005694 — Evaporator Foundation
- 000012459 — Bolt - Evaporator Foundation - M6 x 25mm
- 000006064 — Gearmotor Assembly - 220V/60 Hz/1 Ph
- 000005699 — Gearmotor Assembly - 230V/50 Hz/1 Ph
- 000007822 — Gearmotor Capacitor - 230V/50 Hz/1 Ph
- 000007823 — Gearmotor Capacitor - 220V/60 Hz/1 Ph
- 000005732 — Insulating Cap
- 000005646 — Bearing Cap
- 000005758 — Snap Ring
- 000005600 — Auger Bolt
- 000005610 — Bearing Shim
- 000005651 — Self Lubricating Disc
- 000005606 — Upper Bearing
- 000005736 — Upper O-ring
- 000005649 — Cutter Head
- 000005597 — Auger
- 000005779 — Water Seal
- 000005582 — Lower O-Ring
- 000005780 — Water Seal Retainer
- 000005604 — Lower Bearing
- 000005643 — Flex Jaw Coupling Lower
- 000005644 — Flex Jaw Coupling Spider
- 000005571 — Flex Jaw Coupling Upper
- 000011629 — Ice Chute Assembly
- 000011624 — Ice Chute with Bulb Holder and Bin Thermostat
- 000011620 — Ice Chute with Bulb Holder
- 000011623 — Bin Thermostat
- 000007906 — Ice Exhaust with Microswitch
- 000007907 — Locking Strip
- 000007920 — Cross Bar
- 000007921 — Ice Chute Assembly
- 000007916 — Bulb Holder
- 000007917 — Ice Outlet Pipe Assembly
- 000008643 — Ice Chute Extension
- 000005620 — Compressor - 220V/60 Hz/3 Ph
- 000005618 — Compressor - 415V/50 Hz/3 Ph
- 000006065 — Fan Motor - 220V/60 Hz/3 Ph
- 000005580 — Fan Motor - 415V/50 Hz/3 Ph
- 000005630 — Air Condenser
- 000005637 — Water Cooled Condenser Before Serial Number M04885572010
- 000008628 — Water Cooled Condenser After Serial Number M04885572010
- 000005776 — Water Regulating Valve Before Serial Number M04885572010
- 000008629 — Water Regulating Valve After Serial Number M04885572010
- 000012294 — Water Reservoir Assembly
- 000008462 — Compressor Contactor - 208-230V/60 Hz/1-3 Ph
- 000005764 — Safety Pressure Switch
- 000005761 — High Pressure Switch
- 000005765 — Bin Thermostat
- 000006060 — Fan Cycle Control - 115-230V/50-60 Hz/1 Ph
- 000006191 — Fan Cycle Control - 208-230V/50-60 Hz/1 Ph
- 000005763 — ON/OFF Rocker Switch
- 000005678 — Electronic Noise Reducer
- 000005680 — Electronic Noise Reducer
- 000005760 — Float Microswitch (each)
- 000006058 — Water Inlet Valve - 220V/60 Hz/1 Ph
- 000005772 — Water Inlet Valve - 415V/50 Hz/3 Ph
- 000006050 — Water Inlet Valve Water-cooled Condenser - 208-230V/60 Hz/1 Ph
- 000005773 — Water Inlet Valve - Water-cooled Condenser - 415V/50 Hz/3 Ph
- 000005677 — Drier
- 000011883 — Rotation Sensor
- 000005745 — Compressor Delay Relay - 230V/50-60 Hz/1 Ph
- 000005613 — Capacitor Condenser Fan Motor - 230V/60 Hz/3 Ph or 415V/50 Hz/3 Ph
- 000008689 — Expansion Valve
- 000005689 — Condenser Fan Blade - 208-230V/60 Hz/1 Ph
- 000005573 — Condenser Fan Blade - Water-cooled
- 000005690 — Condenser Fan Guard
- 000006161 — Drain Manifold - 115-230V/60 Hz/1 Ph
- 000005640 — Drain Manifold - 415V/50 Hz/3 Ph
- 000008300 — Drain Manifold - 208-230V/60 Hz/1 Ph
- 000008630 — Drain Manifold - 230-415V/50 Hz/1 Ph
- 000006408 — Fitting - Access Valve
- 000006409 — Core - Access Valve
- 000006410 — Cap - Access Valve
- 000005754 — Reservoir Bracket
- 000009040 — Screw - M5 x 10TC
- 000009041 — Screw - 3.9 x 13TC
- 000009971 — Backflow Preventer 60 Hz - 3/8'
- 000009972 — Backflow Preventer 50 Hz - 3/4'
- 000012328 — Suction Line Assembly
- 000012626 — Suction Line Assembly
- 000012627 — Suction Line Assembly
- 000006055 — Top Panel
- 000006057 — Back Panel - 220V/60 Hz/3 Ph
- 000006103 — Back Panel - 415V/50 Hz/3 Ph
- 000005713 — Back Grill
- 000006056 — Right Side Panel
- 000005715 — Right Side Grill
- 000005788 — Front Panel Assembly
- 000005784 — Air Filter
- 000008683 — Cartoning
Shop RF2300W Parts
About RF2300W Ice Machine Parts
We carry OEM parts for the RF2300W ice machine to help you repair, maintain, and extend the life of your equipment. Use the parts breakdown PDF above to identify the correct component and match it to the products listed on this page.
Popular replacement items may include pumps, valves, sensors, motors, and control components, depending on the machine configuration. Ordering the correct OEM part helps reduce downtime and improves long-term reliability.
