SCCP50
Find Parts for SCCP50
Browse OEM replacement parts for the SCCP50 ice machine and use the parts diagram below to identify the correct component before ordering.
View Parts Diagram for
SCCP50
Looking to buy a new ice machine
to replace this model?
Request a Quote →
Parts associated with SCCP50
- 02-0534-02 — Hose clamp
- 02-1719-00 — Fan blade
- 02-1875-07 — Hole plug
- 02-1875-18 — Hole plug
- 02-2814-08 — Hose clamp
- 02-2814-13 — Hose clamp
- 02-3374-01 — Check valve
- 02-3406-01 — Barbed connector
- 02-3522-01 — Elbow
- 02-3866-03 — Hinge
- 02-3866-04 — Hinge - top left/bottom right
- 02-4197-01 — Fan blade, A series
- 02-4365-01 — Front bracket
- 02-4368-01 — Water Tee
- 02-4369-01 — Drain cap, not used after 6/12
- 02-4370-21 — Spray nozzle, kit. Set of
- 02-4371-03 — Spray platform
- 02-4373-01 — O-ring
- 02-4375-01 — Evap bracket, right
- 02-4375-02 — Evap bracket, left
- 02-4376-01 — Evaporator
- 02-4379-01 — Pump discharge hose
- 02-4380-01 — Light cover
- 02-4381-01 — Barbed fitting
- 02-4381-02 — Spout
- 02-4381-03 — Clip
- 02-4383-01 — Clamp
- 02-4386-01 — Cover
- 02-4390-01 — Kickplate
- 02-4391-03 — Scoop
- 02-4392-01 — Bin edging
- 02-4412-01 — Drain hose
- 02-4413-01 — Drain tube
- 02-4415-01 — Leg cap
- 02-4415-20 — Leg cap, pack of
- 02-4416-01 — Drier
- 02-4426-01 — Insulation pad
- 02-4427-01 — Reservoir
- 02-4428-01 — Drain tube
- 02-4430-01 — Handle, SS
- 02-4430-42 — Handle, white include door panel or hinges
- 02-4430-52 — Handle, black
- 02-4433-01 — Corner block, RH
- 02-4433-02 — Corner block, LH
- 02-4441-01 — Panel handle
- 02-4450-01 — Air baffle
- 02-4474-01 — Hinge package
- 02-4475-01 — Grommet
- 02-4726-01 — Evaporator cover
- 03-1403-16 — Screw
- 03-1403-67 — Screw
- 03-1403-86 — Screw
- 03-1404-10 — Screw
- 03-1404-24 — Screw - hinge to door
- 03-1404-40 — Screw
- 03-1407-08 — Washer
- 03-1410-07 — Lockwasher
- 03-1531-01 — Screw
- 03-1608-01 — Leg leveler
- 03-3811-01 — Screw
- 03-3813-01 — Screw to fill holes
- 03-3818-01 — Screw - hinge to cabinet
- 03-3821-01 — Clip
- 03-3836-03 — Screw
- 03-3892-01 — Thumb screw
- 03-3904-01 — Spring
- 05-0591-01 — Switch hose
- 11-0504-01 — Pressure switch
- 11-0562-21 — Hot gas valve
- 11-0562-22 — HGV coil
- 11-0573-25 — Controller
- 11-0574-01 — Switch panel
- 11-0577-01 — Thermistor
- 11-0580-01 — Magnet, door switch
- 11-0617-21 — Thermostat
- 12-1213-11 — Snap bushing
- 12-2396-02 — Fan motor
- 12-2503-21 — Pump & motor only
- 12-2924-01 — Transformer NS3 12-3000-01 Hi voltage harness, upper
- 12-2986-21 — Water pump, incl 1a
- 12-2990-01 — Inlet water sol valve
- 12-2992-01 — Water sensor harness
- 12-3000-01 — Hi voltage harness, upper
- 12-3000-02 — Hi voltage harness, lower
- 12-3003-01 — Bin stat harness
- 12-3024-01 — Fan motor, A series
- 12-3076-01 — Bin light switch, bulb
- 12-3077-01 — Bulb Note: If replacing the lower harness, always
- 13-0617-04 — O-ring
- 13-0617-11 — O-ring
- 13-0840-01 — Drain plug, changed 6/12.
- 13-0909-01 — Gasket, order
- 13-0943-03 — Gasket strip
- 13-0943-05 — Gasket
- 13-0949-03 — Door gasket
- 16-0671-01 — Elbow
- 18-4700-28 — Grommet
- 18-8939-21 — Compressor
- 18-8939-51 — Overload
- 18-8939-52 — Relay
- 18-8940-01 — Condenser
- 18-8941-01 — Fan blade
Shop SCCP50 Parts
About SCCP50 Ice Machine Parts
We carry OEM parts for the SCCP50 ice machine to help you repair, maintain, and extend the life of your equipment. Use the parts breakdown PDF above to identify the correct component and match it to the products listed on this page.
Popular replacement items may include pumps, valves, sensors, motors, and control components, depending on the machine configuration. Ordering the correct OEM part helps reduce downtime and improves long-term reliability.
