CME1356
Find Parts for CME1356
Browse OEM replacement parts for the CME1356 ice machine and use the parts diagram below to identify the correct component before ordering.
Parts associated with CME1356
- 02-2380-01 — Hinge bushing
- 02-2380-02 — Spacer
- 02-2527-01 — Water distributor
- 02-2628-02 — Receiver A37312-022 Distributor and tubes
- 02-2806-01 — Shoulder screw
- 02-2809-01 — Drain Top
- 02-3195-01 — Door hinge
- 02-3196-01 — Bin hinge
- 02-3201-01 — Drain casting
- 02-3319-02 — Filter dryer
- 02-3337-02 — Ice deflector
- 02-3341-01 — Float
- 02-3383-04 — Float stem, tan for
- 02-3383-05 — Float stem, brown for
- 02-3388-04 — Pump bracket
- 02-3388-05 — Pump bracket
- 02-3396-01 — Insulation for TXV
- 02-3485-01 — Air filter, for front or left side
- 02-3518-01 — Manifold
- 02-3519-01 — Manifold right
- 02-3520-01 — Elbow, rt.
- 02-3534-01 — Reservoir cover
- 02-3613-01 — Elbow
- 02-3614-01 — Flow restrictor
- 02-3660-01 — CME1656 water hose
- 02-3660-02 — CME1356 water hose
- 02-3672-01 — Right trough
- 02-3672-02 — Left trough
- 02-3680-01 — Lower inner splash panel
- 02-3686-01 — Insulation
- 02-3689-01 — Ice sensor holder
- 02-3692-21 — Drain fitting
- 02-3696-02 — Right grommet
- 02-3696-03 — Left grommet
- 02-3699-01 — Panel support clip
- 02-3701-01 — Cover retainer
- 02-3702-21 — Evaporator cover, incl insul
- 02-3703-01 — Drain plug
- 02-3706-01 — Upper inner splash
- 02-3725-01 — Hose clamp
- 02-3740-01 — Thermostat bracket
- 02-3769-01 — Plastic drain
- 02-3769-02 — Track
- 02-3769-04 — Lower frame assembly
- 02-3769-05 — Door with door hinges
- 02-3769-06 — Left hinge
- 02-3769-07 — Right hinge
- 02-3769-08 — Left and right hinges
- 02-3769-09 — Ice gate
- 02-3769-10 — Catch for ice gate
- 02-3769-12 — End plate guide (pair)
- 02-3769-13 — Screws for end plate
- 02-3769-14 — Plugs for end plate
- 02-3769-15 — Ice gate retainer
- 02-3769-16 — Window
- 02-3794-02 — Trim strip
- 02-3823-21 — Top panel, plastic for C - H
- 03-0271-00 — Nut for emblems #25 &
- 03-0727-11 — Baffle screw
- 03-1251-01 — Hex cap screw
- 03-1403-24 — Screw 10-24
- 03-1403-29 — Screw 10-24
- 03-1404-18 — Screw
- 03-1404-37 — Screw
- 03-1405-20 — Bolt
- 03-1406-10 — Nut
- 03-1407-07 — Washer
- 03-1531-01 — Screw
- 03-1539-09 — “E” ring
- 03-1645-01 — Screw
- 03-1691-01 — Nylon screw
- 03-1728-01 — Front panel screw
- 03-1731-02 — Push nut
- 03-1735-01 — Screw
- 11-0501-21 — Hi pressure cut out
- 11-0507-01 — Hot gas valve
- 11-0507-02 — Hot gas valve
- 11-0507-22 — Hot gas valve
- 11-0514-01 — Purge valve
- 11-0514-21 — Coil only
- 11-0515-21 — Temp sensor set
- 11-0521-21 — Bin thermostat
- 11-0531-22 — Purge valve timer 12-2738-01 Lo volt harness, -6 B thru C
- 11-0539-51 — Water level sensor
- 11-0540-21 — Ice sensor (set)
- 11-0608-21 — Water regulating valve 16-0832-02 Stem cap
- 12-1213-10 — Snap bushing
- 12-1213-11 — Snap bushing
- 12-2469-01 — Single phase contactor
- 12-2533-01 — Three phase contactor
- 12-2582-21 — Water pump
- 12-2639-02 — Transformer, -6 B, thru H
- 12-2659-01 — Hi voltage harness, A-C
- 12-2663-01 — Lo voltage harness, A-C
- 12-2665-01 — Harness for water sensor
- 12-2666-01 — Inlet water valve
- 12-2679-01 — Relay, -6 B thru H
- 12-2686-01 — Fuse, -6 B thru H
- 12-2701-01 — Bin thermo harness
- 12-2719-23 — Coil for hot gas valve
- 12-2738-01 — Lo volt harness, -6 B thru C
- 12-2791-01 — Lo voltage harness
- 12-2792-01 — Lo volt harness, -6 D thru H
- 12-2796-01 — Hi voltage harness
- 12-2798-01 — Hi volt harness, -6 B thru H
- 12-2838-24 — Controller Kit 12-2686-01 Fuse, -6 B thru H
- 13-0595-00 — Door gasket( order qty 7)
- 13-0617-11 — O-ring
- 13-0617-48 — O-ring
- 13-0674-02 — Tube, order
- 13-0674-06 — Drain hose, order
- 13-0840-01 — Plug
- 15-0711-02 — Scotsman emblem
- 15-0792-01 — CM3 emblem
- 15-0808-01 — Emblem
- 16-0355-00 — Coupling
- 16-0832-02 — Stem cap
- 16-0832-03 — Port cap
- 16-0832-20 — Access valve
- 16-1031-21 — Accumulator
- 16-1032-01 — Suction manifold
- 16-1032-02 — Suction manifold
- 16-1063-01 — Strainer for hot gas valve
- 16-1066-21 — TXV, ANE1 ¼ SZ
- 17-2502-01 — USE COPPER CONDUCTORS ONLY INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL
- 17-2503-01 — USE COPPER CONDUCTORS ONLY INSTALLED IN ACCORDANCE WITH THE NATIONAL ELECTRICAL
- 17-2511-03 — USE COPPER CONDUCTORS ONLY
- 17-2512-03 — USE COPPER CONDUCTORS ONLY
- 17-2771-01 — CODE AND ALL STATE AND LOCAL CODES.
- 17-2776-01 — UNIT GROUNDED.
- 18-1902-56 — Run capacitor
- 18-2200-27 — Sleeve
- 18-2300-27 — Grommet
- 18-8751-23 — Compressor
- 18-8751-27 — Compressor
- 18-8751-29 — Compressor
- 18-8765-01 — Fan blade
- 18-8767-25 — A - E series water cooled
- 18-8817-01 — Air cooled condenser
- 18-8818-01 — Fan motor
- 18-8840-01 — PTCR
- 18-8840-02 — PTCR Bracket
- 18-8865-21 — F & higher series water cooled 02-3396-01 Insulation for TXV
- 19-0503-04 — Bin gasket (order by foot)
Shop CME1356 Parts
About CME1356 Ice Machine Parts
We carry OEM parts for the CME1356 ice machine to help you repair, maintain, and extend the life of your equipment. Use the parts breakdown PDF above to identify the correct component and match it to the products listed on this page.
Popular replacement items may include pumps, valves, sensors, motors, and control components, depending on the machine configuration. Ordering the correct OEM part helps reduce downtime and improves long-term reliability.
