FME804R
Find Parts for FME804R
Browse OEM replacement parts for the FME804R ice machine and use the parts diagram below to identify the correct component before ordering.
View Parts Diagram for
FME804R
Looking to buy a new ice machine
to replace this model?
Request a Quote →
Parts associated with FME804R
- 02-0836-00 — Catch
- 02-0929-23 — Water Seal
- 02-1338-00 — Hose clamp
- 02-2916-01 — Slotted collar
- 02-2929-03 — Ice Chute Lower
- 02-2930-04 — Ice Chute Cover
- 02-2977-01 — Lip Seal
- 02-2978-01 — Lip Seal
- 02-3001-01 — Ice Sweep
- 02-3128-20 — Breaker Cover
- 02-3266-01 — Reservoir Assembly
- 02-3266-02 — Float valve and seat
- 02-3266-03 — Valve seat 16-1039-01 Male connector
- 02-3319-02 — Dryer
- 02-3559-01 — is a needle that snaps onto a standard grease gun fitting. Use it to insert and deeply
- 02-3575-01 — Fan guard
- 02-3692-22 — Drain fitting
- 02-3826-03 — Res. overflow hose
- 02-3837-01 — Drip Pan
- 02-3841-01 — Ice Chute Body w/ins*
- 02-4358-01 — Insulation wrap
- 02-4663-01 — Water Shed
- 03-0271-00 — Speed Clip
- 03-1394-01 — Pal Nut
- 03-1404-12 — Screw
- 03-1405-20 — Cap Screw
- 03-1405-41 — Cap Screw
- 03-1405-52 — Hex Cap Screw
- 03-1406-04 — Nut
- 03-1406-13 — Nut
- 03-1407-07 — Washer
- 03-1410-06 — Washer
- 03-1419-22 — Screw
- 03-1531-01 — Screw
- 03-1544-08 — Soc. Head Screw
- 03-1645-01 — Cap Screw
- 08-0660-01 — Auger Stud
- 11-0422-25 — Head Pressure Valve
- 11-0488-21 — Thermo Expansion Valve
- 11-0501-22 — Hi Pressure Cut Out
- 11-0502-21 — Pump down control
- 12-0426-02 — Master Switch
- 12-1576-01 — Fan motor
- 12-1868-04 — Crankcase Htr
- 12-2135-01 — Liquid line valve
- 12-2274-02 — Liquid line valve or
- 12-2350-01 — Stand off
- 12-2430-21 — Drive Motor
- 12-2430-24 — Start Switch, Emerson
- 12-2430-29 — Rotor Bearing, Emerson
- 12-2430-44 — Start switch, GE split phase
- 12-2430-49 — Rotor bearing, GE split phase
- 12-2469-03 — Contactor
- 12-2760-21 — Water sensor
- 12-2835-22 — Circuit Board NOT ILLUSTRATED
- 13-0617-45 — O-Ring
- 13-0617-49 — O-Ring
- 13-0617-52 — O-Ring
- 13-0617-54 — O-Ring
- 13-0704-00 — Drip Pan Gasket
- 13-0840-01 — Plug
- 13-0871-01 — Water Shed
- 13-0895-01 — Inlet tubing
- 13-0929-01 — Insulation donut*
- 13-0929-02 — Insulation donut*
- 15-0411-00 — Strike
- 15-0808-01 — Emblem
- 16-0761-01 — Receiver
- 16-0832-02 — Stem cap
- 16-0832-03 — Core cap
- 16-0832-20 — Access valve
- 16-0835-01 — Water Inlet Fitting
- 16-0850-01 — Quick connect fitting, 1/2'
- 16-0850-03 — Quick connect fitting, 3/8'
- 16-1039-01 — Male connector
- 16-1057-01 — Female coupling (3/8')
- 16-1057-02 — Female coupling (1/2')
- 16-1137-01 — Access valve body
- 16-1139-01 — Core
- 16-1140-01 — Cap
- 18-1901-03 — Start Cap
- 18-1902-45 — Run capacitor
- 18-1903-50 — Potential Relay
- 18-2200-27 — Sleeve
- 18-2200-28 — Rubber Grommet
- 18-8708-01 — Fan blade
- 18-8711-50 — Overload 115/60/1
- 18-8721-21 — Compressor 115/60/1
- 18-8796-01 — Fan motor
- 18-8800-01 — Fan blade
Shop FME804R Parts
About FME804R Ice Machine Parts
We carry OEM parts for the FME804R ice machine to help you repair, maintain, and extend the life of your equipment. Use the parts breakdown PDF above to identify the correct component and match it to the products listed on this page.
Popular replacement items may include pumps, valves, sensors, motors, and control components, depending on the machine configuration. Ordering the correct OEM part helps reduce downtime and improves long-term reliability.
