NM1850
Find Parts for NM1850
Browse OEM replacement parts for the NM1850 ice machine and use the parts diagram below to identify the correct component before ordering.
View Parts Diagram for
NM1850
Looking to buy a new ice machine
to replace this model?
Request a Quote →
Parts associated with NM1850
- 02-0929-23 — Water Seal
- 02-2378-01 — Fan Bracket
- 02-2814-01 — Clamp
- 02-2814-08 — Clamps
- 02-2926-01 — Ice Chute Body
- 02-2929-01 — Ice Chute Lower
- 02-2930-01 — Ice Chute Cover
- 02-2933-01 — Hex Stud
- 02-2936-01 — Res. Cover
- 02-2976-01 — Filter Assembly (1)
- 02-2977-01 — Lip Seal
- 02-2978-01 — Lip Seal
- 02-3001-01 — Ice Sweep
- 02-3128-20 — Breaker Cover
- 02-3319-02 — Dryer
- 03-0255-04 — Wing Nut 13. 12-2337-02
- 03-0271-00 — Speed Clip
- 03-1394-01 — Pal Nut
- 03-1404-12 — Screw
- 03-1405-20 — Cap Screw
- 03-1405-41 — Cap Screw
- 03-1405-52 — Hex Cap Screw
- 03-1407-07 — Washer
- 03-1417-13 — Lockwasher
- 03-1417-15 — Lockwasher 11. 12-2285-22 Transformer
- 03-1419-08 — Screw Painted Only
- 03-1531-01 — Screw
- 03-1544-08 — Soc. Head Screw
- 03-1638-03 — Screw (Safety Circuit to Circuit Board)
- 03-1638-04 — Screw
- 03-1645-01 — Screw crankcase heaters)
- 03-1652-02 — Bolt NOT ILLUSTRATED
- 08-0660-01 — Auger Stud
- 11-0424-01 — Water Reg. Valve
- 11-0446-23 — Hi Pressure Cut Out (both are 208-230 volt and have internal overloads &
- 11-0447-20 — Low Pressure Control
- 12-0426-01 — Master Switch
- 12-0739-02 — Three Phase Contactor
- 12-1576-02 — Fan Motor (with screws)
- 12-1741-29 — Rotor Bearing (GE PSC)
- 12-2285-22 — Transformer
- 12-2314-22 — Capacitor, GE PSC only
- 12-2398-01 — Switch, man reset
- 12-2430-22 — Drive Motor
- 12-2430-24 — Centrif. switch (Emerson)
- 12-2430-29 — Rotor Bearing (Emerson)
- 12-2430-44 — Start sw, GE split phase
- 12-2430-49 — Rotor bearing, GE split phase
- 12-2469-02 — Single Phase Contactor (Transformer to Circuit Board)
- 13-0079-03 — Res. Overflow, 8' req.
- 13-0230-00 — Rubber cap
- 13-0617-45 — O-Ring
- 13-0617-52 — O-Ring
- 13-0617-54 — O-Ring
- 13-0674-06 — Evap. Drain, 14' req.
- 13-0704-00 — Gasket
- 13-0868-01 — Water Shed
- 13-0871-01 — Water Shed
- 15-0711-01 — Emblem Water Cooled
- 16-0162-00 — Strainer
- 16-0401-02 — Elbow
- 16-0560-00 — Valve Core
- 16-0563-00 — Valve Cap 18-8879-22 Compressor (3 phase)
- 16-0670-01 — Tee
- 16-0670-02 — Tee
- 16-0780-21 — Thermo Expansion Valve
- 16-0791-01 — Half Union
- 18-1901-48 — Start Capacitor
- 18-1902-45 — Run Capacitor 14. 12-2340-01
- 18-1903-46 — Potential Relay
- 18-2200-39 — Start Capacitor Bracket 9. 11-0447-20 Low Pressure Control
- 18-2300-26 — Sleeve
- 18-3815-01 — Fan Blade
- 18-4300-50 — Start Capacitor Cap. 8. 12-0426-01 Master Switch
- 18-6800-01 — Grommet
- 18-6900-25 — Condenser 16-0563-00 Valve Cap
- 18-7202-01 — Condenser
- 18-8879-21 — Compressor (1 phase)
- 18-8879-22 — Compressor (3 phase)
Shop NM1850 Parts
About NM1850 Ice Machine Parts
We carry OEM parts for the NM1850 ice machine to help you repair, maintain, and extend the life of your equipment. Use the parts breakdown PDF above to identify the correct component and match it to the products listed on this page.
Popular replacement items may include pumps, valves, sensors, motors, and control components, depending on the machine configuration. Ordering the correct OEM part helps reduce downtime and improves long-term reliability.
