NME1250
Find Parts for NME1250
Browse OEM replacement parts for the NME1250 ice machine and use the parts diagram below to identify the correct component before ordering.
View Parts Diagram for
NME1250
Looking to buy a new ice machine
to replace this model?
Request a Quote →
Parts associated with NME1250
- 02-0929-23 — Water Seal 15. 02-3128-20 Breaker Cover
- 02-2814-08 — Hose Clamp
- 02-2929-04 — Ice Chute Lower 16. 13-0840-01 Plug
- 02-2930-04 — Ice Chute Cover
- 02-2977-01 — Lip Seal
- 02-2978-01 — Lip Seal
- 02-3001-01 — Ice Sweep
- 02-3128-20 — Breaker Cover
- 02-3266-02 — Float valve
- 02-3266-03 — Seat/plunger
- 02-3266-20 — Float & Reservoir complete
- 02-3268-01 — Drain hose clip
- 02-3319-02 — Drier
- 02-3333-01 — Fan Motor Bracket
- 02-3692-22 — Drain - Air Cooled
- 02-3837-01 — Drip Pan A32892-001 Drain - Water Cooled
- 02-3841-01 — Ice Chute Body
- 03-0255-04 — Wing Nut NOT ILLUSTRATED
- 03-0271-00 — Clip For Emblem (3)
- 03-1394-01 — Pal Nut
- 03-1403-02 — Screw
- 03-1404-03 — Screw
- 03-1404-12 — Screw
- 03-1405-20 — Bolt
- 03-1405-41 — Cap screw
- 03-1405-52 — Hex Cap Screw 18. 03-1405-41 Cap screw
- 03-1407-07 — Washer
- 03-1417-09 — Washer 13. 03-1405-20 Bolt
- 03-1417-15 — Lockwasher 20. Control Box
- 03-1417-27 — Washer
- 03-1531-01 — Screw
- 03-1531-08 — Screws, motor to bracket
- 03-1544-08 — Soc. head Screw 12. 02-3268-01 Drain hose clip
- 03-1638-03 — Screw
- 03-1638-04 — Screw 19. A37750-021 Circuit Board
- 03-1645-01 — Bolt 12. 03-1407-07 Washer
- 03-1652-02 — Bolt 22. 12-2469-02
- 08-0660-01 — Auger Stud
- 11-0447-20 — L. P. Control
- 11-0482-21 — Expansion Valve 14. 02-3319-02 Drier
- 11-0485-21 — Pressure Control 17. 03-1404-03 Screw
- 11-0608-21 — Water Reg. Valve
- 12-0426-01 — Master Switch (transformer to circuit board)
- 12-1213-10 — Snap Bushing
- 12-1213-11 — Snap Bushing
- 12-2285-22 — Transformer
- 12-2430-22 — Drive Motor 208-230 v
- 12-2430-24 — Centrifugal Switch. Emerson
- 12-2430-29 — Bearing, Emerson
- 12-2430-44 — Centrifugal sw, GE split phase
- 12-2430-49 — Bearing, GE split phase
- 13-0079-03 — Hose 9' Order By Ft. 23b 02-3266-02 Float valve
- 13-0617-45 — O-ring 13. 13-0617-52 O-ring
- 13-0617-52 — O-ring
- 13-0617-54 — O-Ring
- 13-0666-00 — Terminal Cover 23. 12-2337-05
- 13-0674-06 — Tube, 11' Order By Ft.
- 13-0704-00 — Drip pan gasket
- 13-0835-01 — Plastic inlet tubing, use
- 13-0840-01 — Plug
- 13-0868-01 — Water Shed.
- 13-0871-01 — Water Shed
- 15-0711-01 — Emblem for sandalwood
- 15-0808-01 — Emblem for SS or gray
- 16-0162-00 — Strainer - not used after 11/97 24. 03-1394-01 Pal Nut
- 16-0401-02 — Elbow
- 16-0670-01 — Tee
- 16-0670-02 — Tee
- 16-0832-02 — Stem cap 16. 18-5105-02 Fan Motor
- 16-0832-03 — Core cap 03-1531-08 Screws, motor to bracket
- 16-0832-20 — Access valve 15. 11-0447-20 L. P. Control
- 16-0835-01 — Inlet fitting for plastic tube
- 18-1901-15 — Start Capacitor 15. 12-1213-10 Snap Bushing
- 18-1902-53 — Run Capacitor 16. 12-1213-11 Snap Bushing
- 18-1903-33 — Relay
- 18-2200-27 — Sleeve
- 18-2200-28 — Grommet
- 18-2200-39 — Start Cap. Bracket 18. 12-2285-22 Transformer
- 18-3732-01 — Fan Blade
- 18-4300-50 — Start Capacitor Cap 17. 18-1903-33 Relay
- 18-5105-02 — Fan Motor
- 18-6900-25 — Water Cooled Condenser
- 18-8726-23 — 208-230/60/1 Comp. w/drier 18. 03-1417-27 Washer
- 18-8733-01 — Air Cooled Conden.
- 19-0599-06 — Insulation for TXV
Shop NME1250 Parts
About NME1250 Ice Machine Parts
We carry OEM parts for the NME1250 ice machine to help you repair, maintain, and extend the life of your equipment. Use the parts breakdown PDF above to identify the correct component and match it to the products listed on this page.
Popular replacement items may include pumps, valves, sensors, motors, and control components, depending on the machine configuration. Ordering the correct OEM part helps reduce downtime and improves long-term reliability.
